Choosing the correct truss size is one of the most important steps in building a safe and professional stage or event structure. Whether for concerts, exhibitions, weddings, outdoor festivals, or LED screen installations, the right truss dimensions directly affect stability, load capacity, and overall project safety.
This TOURGO guide will help you understand how to select the most suitable aluminum truss size for different applications.
Why Truss Size Matters
- capacity
- Span distance
- Structural stability
- Wind resistance
- Compatibility with lighting and LED equipment
Choosing a truss that is too small may lead to structural risks, while oversized trusses can increase transportation and project costs unnecessarily.
Common Aluminum Truss Sizes
200mm × 200mm Truss
Best For
- Small exhibitions
- Retail displays
- Indoor decoration
- Lightweight lighting setups
Features
- Lightweight and portable
- Easy installation
- Cost-effective
Recommended Span
- Up to 5 meters
290mm × 290mm Truss
Best For
- Medium-sized stages
- Wedding events
- Mobile DJ systems
- Exhibition booths
Features
- Most popular universal size
- Good balance between strength and weight
- Suitable for indoor and outdoor use
Recommended Span
- 6–10 meters
400mm × 400mm Truss
Best For
- Concert stages
- Outdoor events
- Large LED screens
- Roof systems
Features
- High load capacity
- Excellent stability
- Strong wind resistance
Recommended Span
- 10–16 meters
520mm × 760mm Heavy-Duty Truss
Best For
- Stadium concerts
- Large festivals
- Touring productions
- Massive roof structures
Features
- Extremely high load-bearing capacity
- Designed for long spans
- Professional-grade structural performance
Recommended Span
- 16 meters and above
Key Factors When Choosing Truss Size
1. Load Capacity
Consider the total weight of:
- Lighting fixtures
- LED screens
- Speakers
- Decorations
- Roof coverings
Heavier equipment requires larger and stronger trusses.
2. Span Distance
The longer the span, the larger the truss size required.
| Span Distance | Recommended Truss |
|---|---|
| Under 5m | 200×200mm |
| 6–10m | 290×290mm |
| 10–16m | 400×400mm |
| 16m+ | Heavy-Duty Truss |
3. Indoor or Outdoor Use
Outdoor applications require:
- Stronger truss systems
- Better wind resistance
- More stable support structures
For outdoor concerts and festivals, larger trusses are generally recommended.
4. Event Type
| Event Type | Recommended Truss |
|---|---|
| Exhibition Booth | 200×200mm |
| Wedding Stage | 290×290mm |
| Concert Stage | 400×400mm |
| Festival Roof | Heavy-Duty Truss |
| LED Wall Support | 400×400mm or above |
Why Choose TOURGO Truss Systems?
TOURGO provides professional aluminum truss solutions for global event and entertainment projects.
TOURGO Advantages
- High-strength aluminum alloy materials
- Precision welding technology
- Custom truss dimensions available
- Professional engineering support
- Reliable global delivery
Whether you need a compact exhibition truss or a large concert roof system, TOURGO offers safe, durable, and customizable solutions for every project.
Final Thoughts
Choosing the right truss size is essential for ensuring event safety, structural performance, and installation efficiency. By considering load requirements, span distance, and event type, you can select the ideal truss system for your project.
With TOURGO’s professional truss solutions, you can build stronger, safer, and more impressive event structures with confidence.
